| № | Код | Название | Кол-во |
|---|---|---|---|
|
11012
|
CAP
|
2
|
|
|
12053
|
GUIDE-CHAIN,DRIVE,RR
|
1
|
|
|
410
|
WASHER-PLAIN-SMALL,8M
|
6
|
|
|
41034
|
DRUM-ASSY,REAR BRAKE
|
1
|
|
|
41068
|
AXLE,RR
|
1
|
|
|
42041
|
SPROCKET-HUB,48T OPTION
|
1
|
|
|
42041A
|
SPROCKET-HUB,49T OPTION
|
1
|
|
|
42041B
|
SPROCKET-HUB,50T OPTION
|
1
|
|
|
42041C
|
SPROCKET-HUB,47T,AL OPTION
|
1
|
|
|
42041D
|
SPROCKET-HUB,48T,AL OPTION
|
1
|
|
|
42041E
|
SPROCKET-HUB,49T,AL
|
1
|
|
|
42041F
|
SPROCKET-HUB,50T,AL OPTION
|
1
|
|
|
42041G
|
SPROCKET-HUB,51T,AL OPTION
|
1
|
|
|
550
|
PIN-COTTER,3.0X25
|
1
|
|
|
92015
|
NUT,8MM
|
6
|
|
|
92015A
|
NUT,CASTLE,18MM
|
1
|
|
|
92033
|
CIRCLIP,42MM
|
1
|
|
|
92045
|
BEARING-BALL,6004X8JR
|
3
|
|
|
92049
|
SEAL-OIL,MHSA25 42 6
|
2
|
|
|
92057
|
CHAIN,DRIVE,DID520DMA
|
1
|
|
|
92058
|
JOINT-CHAIN,DRIVE
|
1
|
|
|
92143
|
COLLAR,RR AXLE,L=20
|
2
|
|
|
92150
|
BOLT
|
6
|
|
|
92152
|
COLLAR,RR BRAKE DRUM,
|
1
|
|
|
92200
|
WASHER,18.5X32X2.3
|
1
|
-+
