Выбор запчасти
| № | Код | Название | Кол-во |
|---|---|---|---|
|
|
CARBURETOR ASSY, FR
|
1
|
|
|
|
CARBURETOR ASSY, FR
|
1
|
|
|
|
CARBURETOR ASSY, FR
|
1
|
|
|
|
CARBURETOR ASSY, FR
|
1
|
|
|
1
|
.SCREW
|
2
|
|
|
10
|
.PLUG
|
1
|
|
|
11-1
|
.HOSE 5X8X650
|
1
|
|
|
11-2
|
.HOSE 5X8X650 MODEL Y/K1/K2/K3 E3,E28L:650->160
|
1
|
|
|
11-3
|
.HOSE 5X8X675
|
1
|
|
|
11-4
|
.HOSE 5X8X80
|
1
|
|
|
11-5
|
.HOSE 5X8X650
|
1
|
|
|
11A
|
.SPRING
|
1
|
|
|
12
|
.CAP
|
1
|
|
|
13
|
.O RING
|
1
|
|
|
14
|
.HOLDER, GUIDE
|
1
|
|
|
15
|
.PLUNGER ASSY
|
1
|
|
|
16
|
.SPRING
|
1
|
|
|
17
|
.JET, PILOT AIR 65
|
1
|
|
|
18
|
.JET, PILOT 40
|
1
|
|
|
19-1
|
.COVER
|
1
|
|
|
19-2
|
.COVER
|
1
|
|
|
2
|
.RING
|
1
|
|
|
20
|
.DIAPHRAGM ASSY
|
1
|
|
|
21
|
.SPRING
|
1
|
|
|
22
|
.PLATE
|
1
|
|
|
23
|
.SCREW, PLATE
|
1
|
|
|
24
|
.O RING
|
1
|
|
|
25
|
.HOLDER
|
1
|
|
|
26-1
|
.JET, MAIN 90
|
1
|
|
|
26-2
|
.JET, MAIN 90
|
1
|
|
|
27-1
|
.SCREW, DRAIN
|
1
|
|
|
27-2
|
.SCREW, DRAIN
|
1
|
|
|
28-1
|
.CLAMP, SW LEADS
|
1
|
|
|
28-2
|
.CLAMP, SW LEADS
|
1
|
|
|
29
|
.DIAPHRAGM ASSY
|
1
|
|
|
3
|
.CLIP, NEEDLE
|
1
|
|
|
30
|
.SPRING
|
1
|
|
|
31
|
.COVER
|
1
|
|
|
32
|
.SCREW
|
4
|
|
|
33
|
NUT
|
1
|
|
|
34
|
.SCREW
|
1
|
|
|
35-1
|
.LEVER ASSY
|
1
|
|
|
35-2
|
.LEVER ASSY
|
1
|
|
|
36-1
|
.FILTER
|
1
|
|
|
36-2
|
.FILTER
|
1
|
|
|
37-1
|
.O RING
|
1
|
|
|
37-2
|
.O RING
|
1
|
|
|
38
|
.VALVE ASSY, NEEDLE
|
1
|
|
|
39
|
.SCREW
|
1
|
|
|
4-1
|
.WASHER
|
1
|
|
|
4-2
|
.WASHER
|
1
|
|
|
40
|
.FLOAT
|
1
|
|
|
41
|
..PIN, FLOAT
|
1
|
|
|
42
|
SCREW
|
4
|
|
|
43
|
.WASHER
|
1
|
|
|
44
|
.SCREW
|
1
|
|
|
44A-1
|
.HOSE 5X8X650
|
1
|
|
|
44A-2
|
.HOSE 5X8X650
|
1
|
|
|
45
|
.E RING
|
1
|
|
|
46
|
.SCREW, PILOT 1,1/2
|
1
|
|
|
47
|
.SPRING
|
1
|
|
|
48
|
.O RING
|
1
|
|
|
49
|
.WASHER
|
1
|
|
|
5
|
.SPRING
|
1
|
|
|
50
|
RING
|
1
|
|
|
51
|
.SCREW
|
1
|
|
|
52
|
.BRACKET, NO.1
|
1
|
|
|
53
|
.BRACKET, NO.2
|
1
|
|
|
53A
|
HOSE ASSY 5X8X125
|
1
|
|
|
54-1
|
HOSE ASSY
|
1
|
|
|
54-2
|
HOSE ASSY 5X8X125
|
1
|
|
|
55
|
CABLE, ID SYNCRO
|
1
|
|
|
56
|
CABLE, THROTTLE RETURN, F-R
|
1
|
|
|
57
|
CLAMP L:165
|
1
|
|
|
58-1
|
SHEET, HEAT SHIELD MODEL V/W E33~F.NO.V2102739
|
1
|
|
|
58-2
|
SHEET, HEAT SHIELD MODEL V/W E33F.NO.V2102740~MODEL X E33
|
1
|
|
|
59-1
|
HOSE
|
1
|
|
|
59-2
|
HOSE
|
1
|
|
|
6
|
.NEEDLE, JET 5C43-1
|
1
|
|
|
60
|
NIPPLE
|
1
|
|
|
61
|
HOSE, FUEL FILTER TO PUMP MODEL X/Y/K1/K2/K3 E33L:600->500
|
1
|
|
|
62
|
VALVE, AIR VENT
|
1
|
|
|
63
|
BOLT
|
2
|
|
|
7
|
.JET, NEEDLE P-4M
|
1
|
|
|
8
|
.SCREW
|
1
|
|
|
9
|
.SCREW
|
2
|
-+
