| № | Код | Название | Кол-во |
|---|---|---|---|
|
1
|
HUB, REAR WHEEL
|
1
|
|
|
10
|
WASHER
|
1
|
|
|
11
|
NUT
|
1
|
|
|
12
|
SPROCKET, REAR NT:42
|
1
|
|
|
13
|
SCREW 8X30.5
|
6
|
|
|
14
|
WASHER, SEAT DAMPER UPPER
|
6
|
|
|
15
|
NUT
|
6
|
|
|
16
|
ADJUSTER, CHAIN RH
|
1
|
|
|
17
|
DRUM, REAR SPROCKET
|
1
|
|
|
18
|
ABSORBER, REAR HUB SHOCK
|
6
|
|
|
19
|
RETAINER, SPROCKET DRUM
|
1
|
|
|
2
|
SPACER, HUB BEARING
|
1
|
|
|
20
|
BEARING 25X52X15
|
1
|
|
|
21
|
SEAL, DUST 34X52X6
|
1
|
|
|
22
|
RIM, REAR WHEEL MT2.50X17
|
1
|
|
|
23
|
SPOKE SET, REAR WHEEL
|
1
|
|
|
24
|
TIRE, REAR 120/90-17 64S
|
1
|
|
|
25
|
TUBE ASSY, WHEEL INNER
|
1
|
|
|
26
|
PROTECTOR,WHEEL
|
1
|
|
|
27
|
PIN
|
1
|
|
|
3
|
BEARING, REAR HUB
|
2
|
|
|
4
|
OIL SEAL, LH 26X47X5
|
1
|
|
|
5-1
|
DISC, REAR BRAKE MODEL TMODEL V~F.NO.JS1SP46AV2100919
|
1
|
|
|
5-2
|
DISC, REAR BRAKE MODEL VF.NO.JS1SP46AV2100920~MODEL W/X/Y
|
1
|
|
|
6
|
BOLT, DISC
|
6
|
|
|
7
|
AXLE, REAR
|
1
|
|
|
8
|
SPACER, RH
|
1
|
|
|
9
|
SPACER, LH
|
1
|
-+
